Small footprint
CCD vision automatic alignment system
Double-table cutting, cutting range 300*350mm
Small splitting stress, high precision, suitable for PCBA boards of any shape
?CCD automatic optical alignment system
The machine is equipped with an advanced CCD automatic optical alignment system, which can achieve precise positioning and cutting of PCB boards. Whether it is a simple straight line cutting or a complex curve cutting, GAM300 can ensure that every cutting reaches extremely high precision, escorting your product quality.
?High-speed and high-precision spindle
The equipment adopts a high-speed spindle design, with small splitting stress and high precision, and can easily cope with PCBA board cutting tasks of any shape.
?WIN10 operating system, easy to learn and use?
The equipment is equipped with WIN10 operating system and equipped with a self-developed software platform. The operation interface is simple and clear, and the operator only needs simple training to get started. At the same time, the software platform also supports the setting and adjustment of multiple cutting parameters to meet the needs of different models.
?Multiple optional functions to meet personalized needs?
The GAM300 offline milling cutter PCB splitter also provides multiple optional functions such as recording QR code and laser height measurement. These functions can be customized and configured according to your actual needs, making the equipment more suitable for your production needs. Whether it is quality traceability or height measurement, GAM300 can provide you with a full range of solutions.
The end mill height can be automatically compensated to ensure the correct cutting depth.
During the panel separation process, the system detects abnormalities such as end mill slippage, broken tools, or improper installation, preventing PCBA damage.
An optional end mill diameter detection function, combined with end mill usage records, makes tool management easier.
Equipped with high-speed CCD vision automatic calibration system.
Can simulate cutting paths to assist in program programming, ensuring cutting path accuracy.
Combined with full-board scanning and offline programming functions, it enhances path editing efficiency.
Cutting programs can be edited offline and directly imported into the machine, improving utilization rate.
Simpler, more user-friendly, with automatic recognition of cutting paths.
After full-board PCB scanning, editing allows for quick modifications to cutting paths, improving programming efficiency.
Cutting line colors are selectable, making it easier to identify different color PCBs.
Imported high-speed, high-precision spindle.
Low cutting stress, smooth edges, and high precision.
High-precision spindle speed: 80,000 rpm/min
Maintenance time can be set.
Time to clean the dust filter bag.
The system will remind operators to perform maintenance on the equipment regularly.
By calling the existing program, fixture errors are avoided, enabling rapid program retrieval and quick changeover.
ITEMS | GAM300 |
Valid cutting area | 300*350mm |
Process table | Dual tables |
Cutting function | Tweening to line, L shape, Circle, Arc |
Repeat precision | ±0.01mm |
Cutting precision | ±0.05mm |
Spindle | Manual tool change |
Spindle speed | Max.60000RPM Adjustable |
Size of milling tool | ?0.8-3.0mm |
Cutting speed | 1-100mm/s |
Operating system | Windows10 |
Program teaching method | Intuitive teaching by CCD color image input |
Control method | Precision multi-axis control system |
XYZ axis driving mode | AC Servo motor |
Power | Single phase AC220V 50/60HZ |
Dimensions (W x D x H)mm | 1137*1340*1428mm |
Dust collector | Lower dust collector or Upper dust collector(optional) |
