Effective cutting size 600*500mm
Suitable for splitting oversized PCB boards such as servers, PCs, and automotive electronics
A single workbench performs cutting and circuit board placement to increase production capacity.
The visual camera has automatic focus, and there is no need to adjust the focus manually.
It uses a high-speed spindle, has low cutting stress, high precision, and is equipped with an automatic tool change module to achieve automated operation.
The dust collector is equipped with dust detection and alarm function to ensure dust collection effect.
It is equipped with MES online function to provide a management system to integrate production data and monitor equipment status.
By adding a laser height measurement module, the height of the PCBA when placed into the fixture can be checked to ensure it is correct, preventing cutting deviation and damage during the depaneling process due to improper placement of the PCBA or small debris inside the fixture.
By calling the existing program, fixture errors are avoided, enabling rapid program retrieval and quick changeover.
With over 30 years of independent software development, the PCB depaneling machine uses self-developed software, ensuring stability and reliability, and preventing board damage caused by bugs.
The PCB depaneling machine uses an integrated welded design structure, ensuring stability and high strength.
It is made of cast aluminum with a one-piece molding process, offering excellent oxidation resistance, no deformation, no displacement, long service life, and guaranteed precision.
Adopt High-Power Dust Collector
Dust Filtration with HEPA Grade
Equipped with Negative Pressure Detection, providing real-time alerts for dust collection status
Equipped with Floating Brushes (Invention Patent No. ZL201721620742.X) to enhance dust collection efficiency
Optional Central Control System: Unified management and real-time monitoring via network IP.
Remote Device Unified Management: Remote monitoring via mobile app.
| Items | GAM360AT |
| Valid cutting size | 600*500mm |
| Cutting Function | Tweening to straight line,circle and Are |
| Process table | Single table |
| Repeat precision | ±0.01mm |
| Cut precision | ±0.05mm |
| Loading method | Track convey |
| Unloading method | Conveyor or Track convey |
| Spindle speed | MAX60,000RPM |
| Spindle change method | Auto-tool change |
| Program teaching mode | Intuitive teaching by CCD color image input |
| Cut speed | 1-100mm/s |
| Milling bit size | 0.8-3.0mm |
| Pneumatic pressure requirment | 0.6MPa，，，，，，200L/min |
| Dust Collector | TS300L |
| Cut spindle size(W*D*H) | 2309*1606*1717mm |
| Voltage/Power requirement | AC220V，，，，，，1phase,50/60HZ，，，，，，4KW |
| Weight | 930KG |
The online GAM360AT super-large PCB board splitter can be connected to the front and rear ends of the loading and unloading, board receiving machine and other equipment.
